PIR Motion Sensor Module

Detect Motion with Accuracy and Efficiency

The PIR Motion Sensor Module, available at Robogearbd.com, is an essential component for any project requiring motion detection. Utilizing passive infrared technology, this sensor can detect motion by sensing changes in infrared radiation emitted by objects in its field of view. Perfect for security systems, automation projects, and energy-saving applications, the PIR Motion Sensor offers reliable performance and easy integration.

Why Choose PIR Motion Sensor Module?

High Sensitivity: Detects motion with high accuracy by sensing changes in infrared radiation.
Wide Detection Range: Offers a broad field of view, making it ideal for large areas.
Low Power Consumption: Operates efficiently with minimal power requirements.
Easy Integration: Simple to connect with microcontrollers using just three pins: VCC, GND, and OUT.
Versatile Applications: Suitable for use in security systems, automatic lighting, and energy-saving projects.

Product Specifications

Specification	Details
Operating Voltage	5V
Current Consumption	50 µA (standby)
Detection Range	Up to 7 meters
Detection Angle	120°
Output Signal	Digital (HIGH/LOW)
Warm-Up Time	Approximately 1 minute
Interface Pins	VCC, GND, OUT
Dimensions	32 x 24 x 20 mm
Weight	Approximately 10 grams

How to Get Started?

Power the Sensor: Connect the VCC pin to a 5V power source and the GND pin to ground.
Connect to a Microcontroller: Attach the OUT pin to a digital input pin on your microcontroller to read the motion detection signal.
Configure the Sensor: Adjust the sensor's sensitivity and time delay using the onboard potentiometers (if available) to suit your application needs.
Monitor the Output: The OUT pin will go HIGH when motion is detected and LOW when no motion is present. Use this signal to trigger actions or events in your project.
Test and Fine-Tune: Test the sensor's performance in your intended environment and adjust the sensitivity or delay settings as needed for optimal detection.

Implement motion detection in your projects with ease using the PIR Motion Sensor Module. Visit Robogearbd.com to purchase and start integrating motion sensing capabilities today!
